• intoPIX AT

    2024년 6월 8일 - 14일
    부스 #C8363
    회의 예약

smart AV over IP solutions
for manufacturers, integrators and installers!



지연 시간 제로 보장

intoPIX는 무손실 품질과 제로 레이턴시로 전문 AV 네트워크를 위한 혁신적인 이미지 처리 및 압축 솔루션을 만듭니다.

InfoComm는 저희를 만나고 예정된 프로젝트에 대해 논의할 수 있는 완벽한 기회입니다!

      저희 팀과 미팅을 예약하세요!

The most advanced JPEG XS codec with Flawless Imaging!

Codec & IPMX Sub-system FPGA IP cores & integration AddOns

4K60 and 8K60 format with reliable picture quality over 1GbE or 2.5GbE.
• Any AMD® Xilinx, Altera® FPGA with extremely low power and tiny footprint.
• Microsecond Latency: less than 1 millisecond.
• Standard compliant: JPEG XS HIGH444, NEW HIGH420 & NEW FIP with TDC profile.
• Downscaler: Extract 1K, 2K from a 4K stream.
• Low power (ideal for POE).

Integration Addons:
• Fully integrated with the intoPIX IPX-SMPTE2110-22 RTP
Subsystem IP cores
and optional IPX-AES encryption core

for HDCP.
• Compliant with the Adeas / Nextera SMPTE 2110 / IPMX
IP cores.

The world’s fastest JPEG XS software codec available & integration AddOns

Any processor & Any OS:
      ◦ AMD®, Intel®, Apple®, Nvidia®,…
      ◦ x86-64 & ARM64 CPU, CUDA & OpenCL GPU.
      ◦ Linux, Windows, macOS, iOS, Android.
• Any video format.
• Low latency API interface (<1 frame).
• Lossless Quality with JPEG XS HIGH 444 & NEW JPEG XS TDC & FIP for Screen content.
• Embedded downscaler: Extract 1K, 2K from a 4K stream.
NEW RELEASE V3.0: CPU SDK with color and subsampling conversion to ease transcoding,

   up to 25% speed improvements.

Integration Addons:
FFmpeg plugin

• Nvidia Rivermax integration examples

• Deltacast Virtual IP.

Come & see the TicoXS FIP bandwidth & network perfomances !

NEW Error Concealment for robustness to packet losses available directly in the TicoXS FIP-EC codec.
4K HDR over wireless (Wifi-6, 60Ghz) < 750Mbps.
With reliable picture quality, zero latency <1ms. And Low power!
The NEW Titanium Development Kits:
Streaming IPMX, JPEG XS & SMPTE 2110

TitaniumEDK for developers

The Embedded Development Kit provides:
  • ARM64 SoC (ie Rockchip) package.
  • FPGA AdaptiveSoC (AMD-Xilinx ZU+) package.
using the IPX-SMPTE2110-22 FPGA Sub-system IP core.
  • Nvidia Jeston SoC package.
using the IPX-FastTicoXS Codec for Jetson GPU.

  • Support for IPMX with NMOS, ST2110-30 audio and ST2110-22 JPEG XS video.
  •  Easy integration with design examples to support for HD, 4K over 1GbE with an embedded device, running on Linux OS (*).

(*) Video performances vary according to the selected SoC.

TitaniumSDK for developers

The Software Development Kit provides:
  • VSF TR10 (IPMX) with ST2110-20 (uncompressed), -22 (JPEG XS), -30 (audio).
  • NMOS Discovery & Registration.
  • Integrated 1/2.5GbE RJ45 NICs or PCIe NIC cards support (*).
  • Any video format incl. HD, 4K, 8K.
  • Unparalleled quality in live, with intelligent JPEG XS bandwidth usage.
  • Leveraging embedded CPU, multi-processes, and discrete GPU.
  • Integration tools: SDI interfacing, ST2110-20 to -22 IP conversion, framework plugins.
  • Windows 및 Linux OS.

(*) External NIC cards to support high throughput ST2110-20.

Also at the booth ! A Live interoperability demo with multiple-vendors, with 4K / 8K over Gigabit Ethernet & Cat5E with JPEG XS High & FIP.

4K / 8K IPMX over Gigabit Ethernet & Cat5E

The first-of-its-kind demo will be held at the intoPIX Booth C8363, featuring networking equipment and hardware and software running IPMX / SMPTE ST 2110.

The demonstration will showcase various elements of IPMX-enabled AV-over-IP workflows, including cameras, gateways,  reference design, software APPs, with all the power of the latest JPEG XS advances , including JPEG XS High & new JPEG XS TDC profiles.


This demo will illustrate how different sources such as the Panasonic Connect AW-UE160 PTZ (JPEG XS), Adeas Nexteras FPGA core with new intoPIX TicoXS FIP (JXS TDC) cores, and the intoPIX TitaniumShow App can send streams to the intoPIX TitaniumViewer App via the NetGear AV GSM4212px IP Switch, maintaining perfect image quality with zero latency.


With this unique demo, we’re demonstrating the technical viability of IPMX in terms of multivendor interoperability!
intoPIX also participates in the IPMX demonstration at the AIMS Booth C6123.

NEW AV-over-IP Software Apps! TitaniumShow & TitaniumViewer

Create & Display from your PC!


  • User-friendly App that leverages flexible display configurations.
  • With video formats including HD, 4K, 8K & HFR.
  • Use a standard Windows PC with its 1G/2.5Gb integrated Ethernet interface.
  • Take advantage of intoPIX's smart and low latency JPEG XS capabilities.
  • Compliant & interoperable with IPMX VSFTR10 & SMPTE 2110-22 with embedded support of NMOS.


  • User-friendly App.
  • Use a standard Windows PC with its integrated 1G/2.5Gb Ethernet interface.
  • Monitor single to multiple IPMX (VSF TR10) Video, including uncompressed ST2110-20(*) and JPEG XS ST2110-22 streams, with ST2110-30 / AES67 audio.
  • Take advantage of intoPIX's smart and powerful JPEG XS codec capabilities.
  • Embedded support of NMOS to easily discover the available stream and connect.
  • Always with an extremely low latency.
